Type:
Stone Factory MachinesStone Handling, Loading Machines
FOB Price:
$50000-55000
Warranty:
12 Months
Usage:
Granite,Marble,Limestone,Slate,Onyx,Artificial Stone,Basalt,Quartzite,Sandstone,Travertine
Machinery Function Features:
Machinery Function Features
1.Power system
Adopt domestic or international famous brand engines, equipped with engines with higher power reserve than products of the same tonnage, with better power and maneuverability; Dongfang Red and Dongfeng Cummins diesel engines can be selected;
The engine adopts air-intake supercharging and supercharging and inter-cooling technologies to effectively reduce emissions and fuel consumption;
The engine adopts electronically controlled fuel precision injection technology, which is controlled by ECU according to the requirements of different working conditions to make the injection time, pressure and fuel more accurate, and achieve the most optimized power performance, emission performance and economic performance.
采用国内或国际名牌发动机，配置比同吨位产品高功率储备的发动机，动力性更佳，机动性好；可选东方红、东风康明斯柴油机；
发动机采用进气增压及增压中冷技术，有效降低 排放和油耗；
发动机采用电控燃油精确喷射技术，根据不同工况的要求通过ECU的 控制，使喷 射时间、压力和油呈更精确，达到最优化的动力性能、排放性能和经济性能。
2.Transmission变速箱
Adopt domestic famous brand dual-variable integrated fixed-shaft hydraulic gearbox, mechanical and hydraulic control, reasonable matching with power, large torque increase coefficient;
Optional power distribution hydraulic control;optional international famous brand ZF hydraulic gearbox.
采用国内名牌双变一体定轴式液力变速箱，机液控制，与动力匹配合理，增扭系数大；可选配电液控制；可选配国际名牌ZF液力变速箱。
3. Drive axle 驱动桥
According to the characteristics of the axle load distribution during the operation of the telescopic back forklift, the front drive axle with large bearing capacity is adopted, and the axle body adopts an integral type, with a strong ring and good rigidity; adopts a central reduction and wheel-side planetary reduction structure, two-stage reduction, and large output torque;
Use constant velocity universal joint steering drive axle; optional four-wheel drive two-wheel steering or four-wheel drive four-wheel steering off-road vehicle chassis with soft travel, this model has good passability and better maneuverability;
Off-road vehicle drive axle can be equipped with anti-skid system or differential lock to improve the passability of the whole machine under bad road conditions.
根据伸缩背叉车作业时桥荷分布特点采用承载力大的前驱动桥,桥体采用整体式，强度环，刚性好；采用中央减速和轮边行星减速结构，二级减速，输出扭矩大；采用等速万向节转向驱动桥；可选忙四轮驱动两轮转向或四轮驱动四轮转向带软行的越野车底盘，该车型通过性好，机动性更好；越野车型驱动桥可选配防滑系统或差速锁，提高恶劣路况下的整机通过性。
4. Brake 制动器
The service brake adopts two structures of caliper disc type or multi-disc wet type, with good braking performance, customers can choose to match; the multi-disc wet structure brake is maintenance-free, and it is preferred for working conditions that require frequent braking;the brake force booster adopts air pressure or full hydraulic technology, which can be selected by customers;
The full hydraulic booster system has a larger braking force adjustment range; the parking brake adopts negative pressure brake technology, and the brake is released by air pressure or hydraulic pressure, which is light and vertical .
行车制动器采用钳盘式或多片湿式两种结构，制动性能好，客户可选配；多片湿式结构制动器免维护，需频繁制动的工况可优先选用；制动力增力采用空压或全液压技术，客户可选配；全液压增力系统制动力调节范围更大；驻车制动器采用负压制动技术，通过气压或液压释放制动，橾纵轻便。
5.Transmission mode 传动方式
The driving power transmission route adopts two modes: diesel engine-hydraulic gearbox-drive axle-wheels (hydraulic transmission) or diesel engine-hydraulic oil pump-hydraulic motor-drive axle-wheels (hydrostatic transmission), which can be selected by customers.
行驶动力传递路线采用柴油机～液力变速箱～驱动桥～车轮（液力传动）或柴油机～液压油泵～液压马达～驱动桥～车轮（静压传动）两种方式，客户可选配。
6.Arm holder臂架
It adopts a hexagonal cross-section structure, has good torsion and bending resistance, and is made of high-strength steel, which can achieve a lighter frame and improve load-bearing capacity.
采用六边形截面结构，抗扭抗弯性能好，材质为高强度钢，可实现臂架轻呈化，提升承载能力。
7.Cab 驾驶室
The enclosed cab with a large arc streamline shape, 360 ° panoramic view, protective nets outside the front glass and upper glass, beautiful and safe, combined steering wheel instrument panel assembly, humanized interior layout, The seat is equipped with a seat belt, which makes driving comfortable and safe;
Optional cab heating and cooling air-conditioning and full suspension seat, the driver working conditions is Comfortable.
大圆弧流线造型封闭式驾驶室，360°全景，前玻璃和上玻璃外防护网，美观安全，组合式方向盘仪表板总成，人性化内饰布局，座椅配备安全带，使驾驶舒适安全；选装驾驶室冷暖空调及全悬浮座椅，驾驶员工作舒适性好，适应全天候工况。
8. Lighting system 照明系统
The use of LED ring, low-energy lighting and indicator lights provides a clear and adequate working condition for under-lit spaces and night operations, and the driving instructions are more clear.
采用LED环究度、低能耗照明和指示灯具，为照明不足空间及夜间作业提供了明充的工作坏况， 行车指示更沾晰。
9.Security configuration 安全配置
Equipped with mirrors and reversing buzzer; optional reversing radar imaging system, this system multi-point monitoring, wide monitoring range, real-time image display, effectively change the vision of the back, and operate without blind zones;
The hydraulic circuits of luffing, telescoping, tilting and outriggers are all equipped with balance valves, ensuring safe and reliable operation.
配备后视镜和倒车蜂鸣器； 可选装倒车雷达成像系统，本系统多点监控，监控范围广，图像实时显示，有效改变后背视野，无盲区操作；变幅、伸缩、倾斜、支腿液压回路均装有平衡阀，运行安全可靠。
10.Function expansion (multifunctional device) 功能拓展
（多功能属具）
In addition to the standard equipment, it can also be equipped with flat-head buckets, straw forks, adjustable forks, side shift fork, string rods, tire clamps, paper roll oil surge clamps, log clamps, aerial work bars, high-position forage attachments, lifting equipment, glass carrier, impact gun head, one machine with multiple functions to improve efficiency.
除标准设备外，还可配备平头铲斗、草叉、可调叉、侧移叉架、弦杆、轮胎夹、纸卷防油夹、原木夹、高空作业杆、高定位牧草附件、起重设备、玻璃托架、冲击枪头、一机多用提高效率。
